Axon Collection

Full-height interior pivot doors

Phenomenal full-height pivot doors. Always custom-built, always designed to perfection. Custom sizes and designs — choose from solid panel pivot doors, all-glass panel pivot doors, and framed panel pivot doors. Dorsis Axon has become the go-to choice for architects, interior designers, and discerning clients.

Dorsis Axon floor-to-ceiling full height pivot door in gold bronze finish, used with fixed transparent glass panels from the Dorsis Digero collection. Custom home with walnut wood panel ceiling.

Axon Pivot Doors

Three options. Countless designs.

Premium pivot doors for interior use. Axon collection features modern, contemporary, and oversized pivot doors, available in wood, Digero framed glass, and all glass versions. Custom-made to fit modern interiors, perfectly.

Contemporary oversized Axon interior pivot door with painted wood door panel.
Contemporary oversized Axon interior pivot door with Digero aluminum frame glass pivot door panel.
Contemporary oversized Axon interior pivot door with all grass pivot door panel.

Why Dorsis Axon

Every detail perfected

Dorsis Axon Collection - oversized glass pivot door. Aluminum frame in custom RAL 9005 finish. Modern interior.
Any size

A perfect fit for your space — pivot door with custom height up to 9' 10" (3000 mm), and custom width up to 6' 6 ¾" (2000 mm).

Portapivot Stealthpivot - two types of pivot hinges for Dorsis Axon interior pivot doors.
Side or center pivots

Choose side placement of the pivot hinge for narrower pivot doors or middle placement of the pivot hinge for wide openings.

Dorsis Axon glass pivot door frame (Digero 5831 aluminum profile).
Custom aluminum frame

Dorsis Digero 5831 aluminum frame holds 10 mm safety glass and hides the pivot door hinge. Frame available in custom colors.

Textured glass pivot door frame finish in RAL 9005 Jet Black color.
Textured finish

Choose between smooth finish and textured finish. Smooth finish looks rich and glossy, textured finish provides matte appearance.

Parsol Gray glass option for flush-with-the-wall doors with glass panel, pocket door or glass partition wall.
Unique glass options

Choose from a broad selection of glass, including transparent, translucent, brown, satin glass, reflective, or one-way mirror.

Wood Veneers & Colors

Finishes

Explore a collection of premium Italian wood veneers. Customize your doors in every shade of the RAL color palette, in either matte or high-gloss finishes, or opt for the premium Benjamin Moore white and off-white options.

Wood Veneer
Matte Lacqured
Matte Lacquered - Benjamin Moore Collection

Product specifications

Contemporary oversized Axon interior pivot door with Digero aluminum frame glass pivot door panel.

Dorsis Axon Frame

Glass pivot door with aluminum frame
Hinge
AXON
AXON XL
Door weight
Max. 165 lbs (75 kg)
Max. 330 lbs (150 kg)
Width
23 ⅝" — 49 ¼"
(600-1250 mm)
39 ⅜" — 88 ½"
(1251-2250 mm)
Height
Max. 9' 10" (3000 mm)
Max. 9' 10" (3000 mm)
Door frame thickness
31 mm
31 mm
Door glass thickness
⅜" (10 mm)
⅜" (10 mm)
Holding position
-90°/0°/90°
-90°/0°/90°
360° free swing
no
yes
Holding magnetic power
480 N
750 N for heavy doors
480 N
750 N for heavy doors
Top door clearance
7/16" (11 mm)
7/16" (11 mm)
Bottom door clearance
½" (13 mm)
½" (13 mm)
Side door clearance
¼" (5 mm)
¼" (5 mm)
Door edge magnetic catch
Included
Included
Contemporary oversized Axon interior pivot door with painted wood door panel.

Dorsis Axon Wood

Solid core wood pivot door
Hinge
AXON
AXON XL
Door weight
Max. 165 lbs (75 kg)
Max. 330 lbs (150 kg)
Width
23 ⅝" — 49 ¼"
(600-1250 mm)
39 ⅜" — 88 ½"
(1251-2250 mm)
Height
Max. 9' 10" (3000 mm)
Max. 9' 10" (3000 mm)
Door thickness - default
1 ¾" or 2"
2"
Door thickness - custom
yes
yes
Holding position
-90°/0°/90°
-90°/0°/90°
360° free swing
no
yes
Holding magnetic power
480 N
750 N for heavy doors
480 N
750 N for heavy doors
Top door clearance
½" (11 mm)
½" (11 mm)
Bottom door clearance
½" (11 mm)
½" (11 mm)
Side door clearance
¼" (5 mm)
¼" (5 mm)
Door edge magnetic catch
Included
Included

Documentation & CAD data

We will gladly assist you with your planning with the Dorsis AXON pivot doors and provide your project architect or designer with interior door shop drawings for inclusion in your Construction Documents (CD).
